An Aluma Tray replaces your truck's factory box with an aluminum deck. You get the full width of the truck back, four locking storage boxes underneath, a Rhino Lined deck, and a fit kit made for your truck.
Most hard side slide-in campers and overland flatbed campers can be mounted on an Aluma Tray. Tell us your truck and your camper and we'll help you spec the right tray.
Why an aluminum flatbed
No bed walls and no wheel wells in the way. Here's what changes when the factory box comes off.
01
The full width comes back
No wheel wells in the floor. The deck runs flat over the wheels, so the camper uses the whole width of the truck.
02
Storage you didn't have
Four locking boxes under the deck, sealed against dust and water, with weep holes so moisture escapes.
03
Tie downs built in
Camper tie down points are part of the tray, and aircraft L-Track runs both sides of the deck for gear.
Pick the tray by your truck
Short box, long box, or a 60 inch cab to axle chassis cab.
Aluma Tray 6.75'
3/4 ton and 1 ton, short box
Replaces the 6.75 foot bed on a 3/4 ton or 1 ton short box truck. Four locking under-deck boxes and a Rhino Lined deck.
- $11,819Starting at, USD
Aluma Tray 8'
3/4 ton and 1 ton, 8 foot long box
Replaces the 8 foot bed on a 3/4 ton or 1 ton long box truck. Adds a 25 inch bulkhead option over the 6.75 foot.
- $12,879Starting at, USD
Aluma Tray HD-60
1 ton chassis cab, 60 inch cab to axle
Built for 60 inch cab to axle chassis cabs and rated to 5,000 lbs. The 7 inch bulkhead is included.
- $17,820Starting at, USD
An 84 inch cab to axle platform with an 8 foot deck and a large storage garage at the front of the tray. Coming as the 2027 model. Price, weight and load rating are published when the factory signs them off.
Starting prices are MSRP in USD. Every build also needs a chassis mounting kit and a fuel kit, priced by your truck.
A flatbed Four Wheel Camper needs a flatbed under it. Aluma Tray makes side storage box kits sized for Four Wheel Campers on both the 6.75' and 8' trays. Pick the bulkhead first and the side box length follows.
- 6.75' tray70.5" pair with 14" bulkhead
77.5" pair with 7" bulkhead - 8' tray89" pair with 14" bulkhead
96" pair with 7" bulkhead
Gallery
- CNC cut and formed high strength aluminum, garnet media blasted and powder coated
- Rhino Lined deck, four locking under-deck boxes on every model
- Isolated from the frame on steel mounts and urethane bushings, never bolted straight on
- A fit kit made for your truck model. No universal brackets
- One year base warranty and three year structural warranty from Lite Industries
Quote your Aluma Tray build
Send us your truck, box length and camper. We'll come back with the tray, bulkhead and kit that fit.
About 8 weeks: typical lead time, then your tray ships.
